Casappa Kappa 30 Series (KP)

KAPPA pump and motor units consist essentially of a housing and a mounting flange in cast iron of superior mechanical specifications. KAPPA is available with mounting flanges and side or rear ports according to SAE and European standard. The rigidity of assembly and the compact design of KAPPA pumps and motors ensure reliability and high volumetric efficiency also at high operating pressures. Infinite care and attention is taken over the design and construction of each single component, and with quality monitored unceasingly, the result is a consistent, perfectly balanced assembly that guarantees unbroken service under the most arduous operating conditions. KAPPA series is the right choice wherever noise, contamination, non inflammable fluids and size are critical factors. The wide choice of combinations of mounting flanges, shafts and ports ensure to KAPPA series to be applied in a vast range of applications.

Features

• Wide range of displacements
• 0.30 in³/rev (4,95 cm³/rev) to 9.20 in³/rev (150,79 cm³/rev)
• Available in groups 20, 30 and 40
• Max. peak pressure up to 4785 psi (330 bar)
• Max. speed up to 4000 min-1
• High operating pressures
• High efficiency at high temperature
• Low noise emission
• Exceptional working life expectancy
• Solid and compact design
• Custom design
