Continental Hydraulics PowrFlow™ HPV-10 - Axial Piston Pump, 21.1cc/rev

Continental Hydraulics
Contact us for current availability
View all specifications
~ scroll down to find the part you need ~


*Important Update:*

Please note, the Continental Hydraulics HPV pumps are no longer manufacturered and have been replaced by the HPVR - please click here to view the replacement model

Continental Hydraulics are at the forefront of engineering hydraulic solutions for over 50 years-a testament to a long-standing reputation built upon your challenges and opportunities. A worldwide leader- a one-stop-shop for valves, pumps, power units and proportional products-all assembled in the USA.


What Makes PowrFlow™ HPV Series Axial Piston Pumps Your Best Buy?

Variable volume pressure compensated piston pumps match flow to system demand. Your system will generate less heat, and may not need a heat exchanger. Your system can be kept simpler too, with fewer valves and regulators, while still maintaining constant pressure. For long term reliability, and optimum performance,PowrFlow™ HPV Axial Piston Pumps are your best value.


Direct Equivalent

Replace your old Denison PV and Vickers PVB with the Continental HPV range of piston pumps. Output flow sizes are equal to the Denison and Vickers pumps including the 6, 10, 15, 20 and 29 gallons per minute @ 1750 RPM units.  Contact us with your Denison PV or Vickers PVB part number for a direct Continental hydraulics replacement pump.


Features and Benefits
  • Simple Construction for long, dependable service.
  • More contamination-tolerant than competitive pumps to improve dependability and reduce maintenance costs.
  • Quiet operation simplifies meeting system sound level standards.
  • Economical - low overall cost for a high performance variable volume pump.
  • Efficient, energy-saving design.

Description Units
Volumetric Displacement 1.26 cu. in/rev / 21.1 ml/rev
Pump Delivery @ 1750 rpm GPM 9.55 GPM /36.08 LPM
Operating Pressures Intermittent 4000 PSI / 276 Bar
Operating Pressures Continuous 3500 psi / 241 bar
Operating Pressures Minimum 200 psi / 14 bar
Rated Operating Speeds 1750 RPM
Minimum Operating Speeds 500 RPM
Power Input @ 1750 rpm Rated Flow & Pressure 23 hp / 17 kw
Case Drain Flow @ Deadhead & Rated Pressure 0.3 gpm / 1.1 lpm
Mounting Flange Keyed Shaft SAE Type "B" 2-Bolt
Mounting Flange Spline Shaft SAE Type "B" 2-Bolt
Shipping Weight Rear Ports 37 lbs / 16.7 Kg
Shipping Weight Side Ports 48 lbs / 21.8 Kg
Shipping Weight Tandem Ports 51 lbs / 23.1 Kg
