| Description | ND 89-200-40 | ND 89-201-40 | ND 81-301-40 |
|---|---|---|---|
| Displacement Volume | 8 cm³/rev | 8 cm³/rev | 8 cm³/rev |
| Motor Capacity Output/Pole No | 0.4 KW/4P | 0.75 KW/4P | 0.75 KW/4P |
| Tank Volume | 20 Ltr | 20 Ltr | 30 Ltr |
| Max Operating Pressure | 3.5 MPa {35 kgf/cm²} | 3.5 MPa {35 kgf/cm²} | 7 MPa {70 kgf/cm²} |
| Pressure Adjusting Range | 0.8 ~ 3.5 {8 ~ 35 kgf/cm²} | 0.8 ~ 3.5 {8 ~ 35 kgf/cm²} | 0.8 ~ 7 {8 ~ 70 kgf/cm²} |
| Displacement Volume Set at Factory (50Hz) | 6 L/min | 11.5 L/min | 6 L/min |
| Displacement Volume Set at Factory (60 Hz) | 7 L/min | 14 L/min | 7 L/min |
| Pressure Set at Factory | 3.5 MPa {35 kgf/cm²} | 3.5 MPa {35 kgf/cm²} | 7 MPa {70 kgf/cm²} |
| Weight | 45 kg | 50 kg | 53 kg |
